Ciena 3903
Overview:
Designed for small and medium business applications requiring reliable GbE services, Ciena’s 3903 Service Delivery Switch is an advanced Ethernet business demarcation platform in a compact form factor.
Reliability and Performance:
The 3903 includes Ciena’s performance test hardware engine to provide RFC2544 and Y.1564 benchmark performance test capabilities, enabling full line-rate, customer traffic measurements end to end across the Ethernet Virtual Circuit (EVC). Performance testing also improves end-customer satisfaction by enabling the Network Operations Center (NOC) to be very responsive to SLA impacts and increasing the performance metrics available for end-customer SLA reporting.
Technical specifications
| INTERFACES | MANAGEMENT | PHYSICAL |
|---|---|---|
| 2 x 100/1000M SFP NNI/UNI ports 1 x 10/100/1000M RJ-45; 100/1000M SFP UNI combo port 1 x Console Port (RJ-45, EIA-561) | Enhanced CLI CLI-based configuration files SNMPv1/v2c/v3 SNMPv3 Authentication and Message Encryption RFC 1213 SNMP MIB II, 1493 Bridge MIB, 1573 MIB II Interfaces, 1757 RMON MIB, 2021 RMON II, 2866 RADIUS Accounting, 1350 Trivial TFTP Per-VLAN Statistics RADIUS Client and RADIUS Authentication Secure File Transfer Protocol (SFTP) Secure Shell (SSHv2) Syslog with Syslog Accounting Port State Mirroring Virtual Link Loss Indication/Remote Link Loss Forwarding (VLLI/RLLF) Dual-Stack IPv4/IPv6 management plane Local Console Port Comprehensive Management via Ethernet Services Manager Remote Auto configuration via TFTP, SFTP Software download/upgrade via TFTP, SFTP | Mounting: Wall, desktop, rack Dimensions: > 8.5" (W) x 8.0" (D) x 1.5" (H) > 216mm (W) x 204mm (D) x 38mm (H) Weight: 3.0lbs; 1.4kg |
| POWER REQUIEREMENTS | ETHERNET SERVICES | |
| Two built-in redundant power supplies DC Input: -48, -/+ 36, -/+24 VDC (nominal) AC Input: 100V, 240V AC (nominal) AC Frequency: 50/60 Hz Maximum Power Input: 52W | IEEE 802.1ag Connectivity Fault Management (CFM) IEEE 802.3ah Ethernet in the First Mile (EFM) IEEE 802.1AB Link Layer Discovery Protocol (LLDP) ITU-T Y.1731 Performance Monitoring RFC 2544 Performance Benchmarking Test Generation and Reflection up to 1GE ITU-T Y.1564 Ethernet Service Activation Test Methodology RFC 5618 TWAMP Responder and Receiver TWAMP Sender TWAMP +/- 1ms timestamp accuracy Dying Gasp with Syslog and SNMP Traps |
Overture 1400
Overview:
The Overture 1400 is a modular 1 gigabit Carrier Ethernet edge platform that enables ubiquitous Ethernet services from 1Mbps to 1Gbps over both native Ethernet and the existing TDM infrastructure. For native optical Ethernet networks, the Overture 1400 provides a complete edge solution with six tri-speed interfaces. When native optical Ethernet is not available, the flexible network interface slot may be used for Carrier Ethernet over existing SONET/SDH and PDH (DS3/E3, DS1, E1) networks. The Overture 1400 provides a complete toolkit for service differentiation and performance assurance along with the operational savings that comes from a single flexible platform.
The Overture 1400 GigE Carrier Ethernet edge platform was developed in conjunction with leading service providers and is unique in three fundamental areas:
Reliability and Performance:
Carrier class means 99.999% availability, sub-50ms protection switching, and low-latency line-rate throughput on every interface. The compact, temperature-hardened Overture 1400 is designed for the demanding environments of the telco central office, outside plant cabinet, datacenter or enterprise wiring closet. In addition, the 1400 provides the resiliency and monitoring features required for high-performance financial services and data center applications.
Technical Specifications:
| INTERFACES | MANAGEMENT | PHYSICAL |
|---|---|---|
| 4 x 10/100/1000 Electrical 6 x SFP, SX/LX/ZX/CWDM Hot-swappable interface modules > 1 x OC3/OC12 or STM1/STM4 > 4 x OC3/OC12 or STM1/STM4 > DS3/E3 > 3 x DS3/E3 (Rel. 12.1) > 8 x DS1/E1 | Supports local and inband management 802.3ah, 802.1ag, Y.1731 RFC2544 (R12.1) 256 MEPs UNI 2.2 E-LMI LAN/WAN fault propagation (Rel. 12.1) LLDP (Rel.12.1) SNMPv3 RADIUS Syslog | Dimensions: 1.75H” x 17W” x 8D” (45 mm x 430 mm x 200 mm) Mounting: 1RU in standard 19” or 23” rack Weight: 5 lb (2.26 kg) maximum Operating temperature: -40° to +149°F (-40° to +65°C) Humidity: 5-90% non-condensing relative humidity Hot-swappable redundant power supplies and optics Input voltage: -48VDC, AC Power |
| CONFIGURATION OPTIONS | ETHERNET SERVICES | COMPLIANCE AND CERTIFICATION |
| MEF E-LINE, E-LAN and E-TREE Network interfaces: > 2 GigE, sub-50ms LACP > OC3/OC12 1+1 APS > STM1/STM4 1+1 APS > Line-rate 1GigE over 2 x OC12/STM4 > Line-rate 1GigE over dual-protected > OC12/STM4 > DS3/E3 (X.86, GFP) > 3 x DS3/E3 (PDH/VCAT/LCAS) > 8 x DS1/E1 (PDH/VCAT/LCAS or > MLPPP bonding | 128 EVCs Triple tag management Hierarchical QoS 128 dedicated queue groups, 1024 queues LACP, 50ms protection Dynamic p-bit marking (Rel. 12.1) | CE Mark EN 60950 FCC Part 15, EN 55022 MEF 9, 14, 20 NEBS Level 3, Zone4 RoHS WEEE |
Cisco ME 1200
Overview:
The Cisco ME 1200 Series Ethernet Access Device provides all the features required for MEF 2.0 service initiation, including services such as ELINE, ELAN, and EACCESS. To help maintain proper QoS for these services, the Cisco ME 1200 Series offers rich traffic classification and hierarchical QoS for per-port per services. To help ensure that service level agreements (SLAs) are enforced, ingress traffic policing and egress shaping are also supported.
Reliability and Performance:
As more advanced network services move into the cloud or data center, there is a need for a device with a low port density with carrier grade Ethernet, advanced QoS, and performance measurement capabilities. With low latency and OAM performed in hardware, the Cisco ME 1200 Series Ethernet Access Device resides close to the customer, providing service assurance while network services are remote in the data center.
Technical Specifications:
| INTERFACES | MANAGEMENT | PHYSICAL |
|---|---|---|
| 2 x RJ45 Gigabit Ethernet interface 4 x Gigabit Ethernet interfaces | Management Options > Standalone mode with Webgui > Standalone mode with Prime Network, Prime Provisioning, Prime Performance > Controller mode with Controller on ME3600X and ME3800X Zero Touch provisioning (ZTP) Syslog SNMP v1, v2, v3 (crypto, non-crypto) DHCPv4 client DHCP server RMON SSL Simple Network Management Protocol (SNMP) XML over HTTPS WSDL data model | Dimensions: > 10.6”(W) x 1.75”(H) x 7.1”(D) > 269mm(W) x 44mm(H) x 180mm(D) Weight: > ME1200-4S-A: 2.84 lb (1.29 Kg) > ME1200-4S-D: 3.13 lb (1.42 Kg) |
| POWER REQUIEREMENTS | ETHERNET SERVICES | |
| AC Input: 100-240VAC, 50-60Hz DC Input: 20.5V to 72VDC | IEEE 802.1ag Connectivity Fault Management (CFM) IEEE 802.3ah Ethernet in the First Mile (EFM) IEEE 802.1AB Link Layer Discovery Protocol (LLDP) ITU-T Y.1731 Performance Monitoring RFC 2544 Performance Benchmarking Test Generation and Reflection up to 1GE ITU-T Y.1564 Ethernet Service Activation Test Methodology RFC 5618 TWAMP Responder and Receiver TWAMP Sender TWAMP +/- 1ms timestamp accuracy Dying Gasp with Syslog and SNMP Traps |
